Incabloc Spring 170.02 = 170.03 = 170.13 ( Arogne, ETA, Valjoux, Enicar, FHF, ST, Omega and more )
Incabloc Spring 170.02 = 170.03 = 170.13 ( Arogne, ETA, Valjoux, Enicar, FHF, ST, Omega and more )
Incabloc Spring 170.02 = 170.03 = 170.13
Omega 330, Omega 355, Valjoux 7750, Valjoux 7730, Valjoux 7733, Valjoux 7734, Valjoux 7736, Valjoux 7737, Valjoux 7739, Valjoux 7741, Valjoux 7755, Valjoux 7765, Valjoux 7770, Valjouc 23, Valjoux 72, Valjoux 88, Valjoux 90, Valjoux 230, Valjoux 232, Valjoux 724, Valjoux 886, ETA 2801, Eta 2824-2, ETA 2836-2, ETA 2834-2, ETA 2892, St 69, ST 69-21, ST 96, ST 1686, ST 1800, ST 97, FHF 55, FHF 67, FHF 67-4, FHF 72, FHF 905, Enicar, Arogno 151, Arogno 152, Upper As 969, AS 976, AS 984, AS 1001, AS 1012, AS 1677, AS 1051, AS 1058, AS 1287, AS 1130, and many more.
no 1
For this calibre we acknowledge the following parts as a base:
182 Barrel (drum and cover)
195 Barrel arbor
200 Center wheel with cannon pinion
201 Center wheel without cannon pinion
203 Center wheel and pinion intermediaire
206 Center wheel drilled without pinion
210 Third wheel
220 Fourth wheel, second wheel
224 Fourth wheel long pivot
227 Sweep second wheel
240 Cannon pinion
245 Cannon pinion for sweep second wheel
250 Hour wheel
260 Minute wheel
275 Sweep second pinion
301 Regulator for flat hairspring
307 Regulator for breguet hairspring
401 Stem
404 Stem male/female
407 Clutch wheel
410 Winding pinion
415 Ratched wheel
420 Crown wheel
422 Crown wheel ring
423 Crown wheel core, upper
425 Click
430 Click spring
434 Clicking spring
435 Yoke
437 Rocking bar
440 Yoke spring
443 Setting lever
445 Setting lever spring
453 Intermediate setting wheel
462 Minute work cock
704 Escape wheel for lower endpiece
705 Escape wheel
710 Juwelled pallet fork
711 Pallet with lower endstone
721 Balance complete
723 Balance staff
728 Balance staff
730 Plateau
771 Mainspring
790 Pin escape wheel
792 Balance staff
797 Pin pallet fork for roller
798 Finger
800 Pin pallet fork for finger
If the part you need it not available or listed, do not hesitate to contact us.
Below figure is an example for this calibre type:
