HB 414
Our selection of spare parts for this calibre: HB 414
For this calibre we acknowledge the following parts as a base:
182 Barrel (drum and cover)
195 Barrel arbor
200 Center wheel with cannon pinion
201 Center wheel without cannon pinion
203 Center wheel and pinion intermediaire
206 Center wheel drilled without pinion
210 Third wheel
220 Fourth wheel, second wheel
224 Fourth wheel long pivot
227 Sweep second wheel
240 Cannon pinion
245 Cannon pinion for sweep second wheel
250 Hour wheel
260 Minute wheel
275 Sweep second pinion
301 Regulator for flat hairspring
307 Regulator for breguet hairspring
401 Stem
404 Stem male/female
407 Clutch wheel
410 Winding pinion
415 Ratched wheel
420 Crown wheel
422 Crown wheel ring
423 Crown wheel core, upper
425 Click
430 Click spring
434 Clicking spring
435 Yoke
437 Rocking bar
440 Yoke spring
443 Setting lever
445 Setting lever spring
453 Intermediate setting wheel
462 Minute work cock
704 Escape wheel for lower endpiece
705 Escape wheel
710 Juwelled pallet fork
711 Pallet with lower endstone
721 Balance complete
723 Balance staff
728 Balance staff
730 Plateau
771 Mainspring
790 Pin escape wheel
792 Balance staff
797 Pin pallet fork for roller
798 Finger
800 Pin pallet fork for finger
1143 Oscillating weight
1155 Lower cock for reduction gear
1196 Oscalating weihgt Axle
1423 intermediate driving wheel for ratchet wheel
1428 stop click
1446 Ratchet wheel lower
1453 double function automatic spring
1471 stop pinion
1478 Oscillating weight wheel
1480 winding-up wheel
1482 Driving gear, mounted
1483 Rachet cq Crown wheel driver
1485 Reverser, monted
1488 Pawl winding wheel, complete
1489 Pawl winding wheel, automatic
1491 Oscillating weight bolt
1496 Oscilater weight axe
1498 Bearing wheel for oscillater weight
1499 reverser connecting wheel
1500 Wig-wag pinion
1509 Wig wag pinion spring
1530 Coupling clutch, mount
1535 Reversing Wheel
1555 winding wheel bolt
2557/1 Date star, with dial disk
2561/1 Day star with dial disk
2529 Lid for date Jumper Spring
2535 Date indicator Maintaining Plate
2536 Addition indicator maintaining small plate
2539 Date corrector operating lever
2542 Date setting wheel
2543 Intermediate date wheel
2544 Date corrector pinion
2555 Calendar driving wheel
2556 Date star driving wheel
2557 Date star
2558 Double-toothed hour wheel
2560 Day star driving wheel
2566 Date corrector
2567 Day corrector
2568 Month corrector
2569 Double corrector
2571 Day corrector spring
2573 Day jumper spring
2575 Date jumper spring
2576 Date jumper
2577 Day jumper
2595 Date Jumper maintaining plate
2611 Jumper spring
2632 Date unlocking yoke
2633 Date Unlocking yoke Spring
2638 Lever Slide spring
2742 Corrector Mechanism
2765 Date corrector yoke
2780 Date indicator spring clip
2783 Instantaneous Unlocking Mechanism
2784 Double Jumper
2790 Calendar finger
If the part you need it not available or listed, do not hesitate to contact us.
Below figure is an example for this calibre type:
![](https://primary.jwwb.nl/public/s/v/y/temp-pdzgqzmvalrljvccvpkk/bqbqg0/AutomaatDatum-ETA289713-2.png?enable-io=true&enable=upscale&crop=610%2C1213%2Cx0%2Cy0%2Csafe&width=467&height=929)
![](https://primary.jwwb.nl/public/s/v/y/temp-pdzgqzmvalrljvccvpkk/2egk3s/AutomaatDatum-ETA289723-2.png?enable-io=true&enable=upscale&crop=680%2C1134%2Cx0%2Cy0%2Csafe&width=467&height=779)
![](https://primary.jwwb.nl/public/s/v/y/temp-pdzgqzmvalrljvccvpkk/xp3h8f/AutomaatDatum-ETA289733-2.png?enable-io=true&enable=upscale&crop=509%2C1481%2Cx0%2Cy0%2Csafe&width=467&height=1359)
